Product Information
Embrace limitless design possibilities with PRSE's cutting-edge flexible circuitry. Our specialized Flex PCBs deliver exceptional bendability for compact, moving parts, while our integrated Rigid-Flex systems merge sturdy platforms with agile connections to replace bulky, unreliable wiring. This advanced approach enhances product resilience, streamlines manufacturing, and empowers breakthrough innovations across industries - from life-saving medical devices to next-generation aerospace technology.
Partner with us to build smarter, lighter, and more durable electronic products.
| Number of Layer | 6L (2R+2F+2R) |
|
| Final Thickness | 1.7±0.15mm | |
| Line Width / Line Spacing | 0.127mm / 0.12mm (Inner Layer) 0.1mm / 0.12mm (Outer Layer) | |
| Minimum Hole Size | 0.3mm | |
| Copper Thickness | Surface ≥ 35um, PTH ≥ 18um | |
| Surface Finish | ENIG | |
| Unit Size | 68*148mm | |
| Business Segment | Industrial CNC Control Panel |
| Number of Layers | 2L + stiffener + back adhesive |
|
| Final Thickness | 1.7±0.15mm | |
| Plating Aspect Ratio | 14:1 | |
| Minimum Hole Size | 0.15 mm | |
| Minimum line width/line spacing | 4/4mil | |
| Copper Thickness: | Surface ≥ 35um, PTH ≥ 30um | |
| Surface Finish | ENIG | |
| Unit Size | 254*145.5mm | |
| Business Segment | Consumer Electronics |
| Number of Layers | 12L (5R+2F+5R) 3 Step HDI |
|
| Final Thickness | 1.762 ±10% | |
| Line Width / Line Spacing | 0.15 mm/0.15 mm (Inner Layer) 0.1mm/0.14mm (Outer Layer) | |
| Minimum Hole Size | 0.3mm | |
| Copper Thickness | Surface ≥ 35um, PTH ≥ 18um | |
| Surface Finish | Immersion Silver | |
| Unit Size | 30.7 * 57.4 mm | |
| Business Segment | Medical Equipment |
| Number of Layers | 4L (3R+1F) |
|
| Final Thickness | 1.6±0.16mm | |
| Line Width / Line Spacing | 0.15 mm / 0.15 mm | |
| Minimum Hole Size | 0.3mm | |
| Copper Thickness | Surface ≥ 35um, PTH ≥ 18um | |
| Surface Finish | ENIG | |
| Unit Size | 210*140mm | |
| Business Segment | Medical Equipment |
